dotMod dotBox 220 V2 Vape Kit

Description - dotMod dotBox 220 V2 Vape Kit

The dotMod dotBox 220 V2 Vape Kit pairs the dotBox 220W V2 mod with the dotTank Max V2 sub-ohm tank, creating a dual-18650 setup built for vapers who want serious wattage and precise control in a single box. Powered by 2 x 18650 batteries (sold separately), the mod puts out 5 to 220W across seven modes, including Curve and Boost for advanced power shaping. The dotTank Max V2 brings a clean top-fill system, adjustable top airflow, and an 810 widebore drip tip, covering everything from a relaxed RDL (restricted direct lung, a draw tighter than full DTL but more open than MTL) to a wide-open DTL (direct-to-lung) pull. This is a kit for experienced vapers, cloud chasers, and flavour-focused DTL users who are ready to step up to a flagship-level setup. Browse the full dotMod collection at Vaping101, with fast UK delivery and a 1-year warranty on hardware.

If you want a high-wattage kit that looks and performs like a premium product, the dotBox 220 V2 delivers on both counts.

Introducing the dotBox 220 V2 Vape Kit

DotMod has built a reputation for hardware that feels as refined as it performs, and the dotBox 220 V2 Vape Kit is a strong example of that approach. The mod itself is constructed from lightweight aluminium alloy, which keeps the dual-18650 chassis manageable in daily carry without sacrificing rigidity. The 1.08-inch colour screen is clear and easy to read, and the fully customisable luxury theme lets you personalise the display to your preference.

The dotTank Max V2 is a 25mm sub-ohm tank with an 810 widebore drip tip, designed to match the mod's output range. Top-fill loading keeps refills quick and clean, and the adjustable top airflow reduces leak risk compared to bottom-airflow designs while still delivering the open draw that DTL vaping requires. The dotCoils V2 platform covers a range of resistances, so you can shift between RDL and DTL performance by swapping coils rather than replacing the whole tank.

Seven power modes including PM, BP, NI, TI, SS, Curve, and Boost give you more granular control than most regulated mods at this price point. Curve mode lets you programme a custom wattage ramp so you can climb gradually to your preferred power level, which is particularly useful when breaking in a fresh coil. Boost mode fires at a slightly elevated wattage at the start of each puff before settling at your set level, adding a sharper initial hit for vapers who prefer a more pronounced draw.

This kit is built for experienced vapers who want power, control, and a finish that holds up to daily use.

Why Choose the dotBox 220 V2 Vape Kit?

• Device style: Premium dual-18650 high-wattage kit, mod and sub-ohm tank included

• Battery and power: 2 x 18650 batteries (not included), 5 to 220W adjustable output

• Modes: PM, BP, NI, TI, SS, Curve, and Boost for tailored power delivery

• Airflow: Adjustable top airflow on the dotTank Max V2, covering RDL to full DTL draws

• Display: 1.08-inch colour screen with fully customisable luxury theme

• Safety: Manual lock/unlock switch plus multiple built-in protections including short circuit, overheat, and overcharge

• Coil platform: dotCoils V2 series, compatible with multiple resistances for different power levels

• Charging: USB-C built in; external charger recommended for 18650 longevity

• Build quality: Lightweight aluminium alloy construction throughout, both mod and tank

• Best for: Experienced vapers, DTL and RDL users, cloud chasers, flavour-focused setups

The aluminium alloy build keeps weight down without cutting corners on rigidity. The manual lock/unlock switch is a practical addition on a kit this powerful, preventing accidental firing in a pocket or bag.

The seven-mode chipset gives you more control over your vape than most kits in this price bracket, from gentle RDL sessions to high-output DTL clouds.

Compatibility and Performance

• Compatible coils: dotCoils V2 series. Two coils are included in the box. Different resistances in the V2 range suit different wattage preferences, from mid-range RDL outputs to higher-power DTL builds.

• E-liquid type: High-VG shortfills (70/30 VG/PG or higher) for DTL vaping at full airflow. Higher-resistance dotCoil V2 options can pair with 50/50 blends at tighter airflow settings for an RDL experience.

• Output character: Responsive across the full wattage range. Boost mode adds extra punch at the start of each puff; Curve mode lets you map a custom wattage ramp to climb gradually into your preferred power level.

• TC modes: NI (nickel), TI (titanium), and SS (stainless steel) temperature control for supported wire types. TC vaping sets a maximum coil temperature to reduce the risk of dry hits as the tank runs low.

• Tank capacity: dotTank Max V2, 25mm diameter, top-fill design with 810 widebore drip tip for open DTL draws.

• Charging: USB-C cable included. A dedicated external 18650 charger is recommended for long-term battery health.

• Battery note: Use matched, high-drain 18650 cells rated at 20A continuous discharge or above for higher wattage use. Mismatched batteries in a dual-battery mod cause uneven discharge and accelerated wear. Browse 18650 batteries to pair correctly.

For DTL vaping at full airflow, the dotTank Max V2 performs best with high-VG shortfills. The thicker liquid wicks efficiently through the dotCoils V2 mesh and produces the dense vapour the tank is designed around. Tighten the airflow and move to a higher-resistance V2 coil and a 50/50 blend, and the same tank shifts into a solid RDL setup.

Because the dotCoils V2 platform covers a range of resistances, you can move between RDL and DTL performance simply by swapping coils, without replacing any other part of the setup.

dotBox 220 V2 Vape Kit Highlights

Designed for vapers who want power and refinement in one package, these are the features that define the dotBox 220 V2 Kit day-to-day:

• 5 to 220W output from a dual-18650 configuration, covering everything from light RDL use to high-output DTL clouds

• 7 power modes including Curve (custom wattage ramp) and Boost (elevated starting punch)

• dotTank Max V2 with top-fill loading for clean, no-fuss refills

• Adjustable top airflow for an RDL-to-DTL draw range with reduced leak risk versus bottom-airflow designs

• 1.08-inch colour screen with a fully customisable luxury display theme

• Manual lock/unlock switch for safe carry without accidental firing

• Aluminium alloy construction throughout, keeping the kit lightweight relative to its power output

The top-airflow design on the dotTank Max V2 is worth highlighting on its own. Most sub-ohm tanks at this output level use bottom airflow, which can introduce leak risk when the tank is stored horizontally. Moving the airflow to the top removes that variable entirely, making the kit considerably more practical for daily use.

These features combine into a setup that performs well at the top of its power range while remaining straightforward to use every day.

Box Contents

Everything you need to get started, just add 2 x 18650 batteries and your preferred e-liquid:

• 1 x dotBox 220W V2 mod

• 1 x dotTank Max V2 sub-ohm tank

• 2 x dotCoils V2 coils

• 1 x Replacement glass tube

• 1 x Accessory bag

• 1 x USB-C cable

• 1 x User manual

The dotBox 220 V2 Vape Kit is in stock at Vaping101 with fast UK shipping options, including next-day delivery to most UK postcodes on orders placed before 1:00 PM Monday to Friday. All hardware comes with a full 1-year warranty as standard, and you can return any unused, undamaged product within 14 days of delivery.

Pick up a set of dotCoils V2 replacements and a pair of 18650 batteries at the same time so you're fully set up from day one.

dotBox 220 V2 Vape Kit Specifications

Specification	Detail
Mod output	5W to 220W
Battery	2 x 18650 (sold separately)
Modes	PM, BP, NI, TI, SS, Curve, Boost
Display	1.08-inch colour screen
Tank	dotTank Max V2
Tank diameter	25mm
Drip tip	810 widebore
Airflow	Adjustable top airflow
Coils	dotCoils V2 (2 included)
Fill method	Top fill
Material	Aluminium alloy
Charging	USB-C
Vaping style	RDL, DTL
Connection	510 thread
